Light Guide Panels

We build panels to order based on your specifications and dimensions. Thin, fully customizable luminous panels are ideal for lighting retail displays, graphics, walls, stretch ceilings, countertops, and other glowing surfaces.

Features & Benefits

Assembled in the USA
Even illumination in a thin, diffused panel
Static white colors, RGB, and tunable white
Built to order in any size up to 54 in. x 94 in.

Spec Sheet

• 5 Year Limited Warranty

• Assembled in the USA

SKU Builder

Make

Voltage

Model

CCT

Dimensions

Diffusion

Edges Lit

Frame Color

Lead Wire

Color

Length

Connection

Exit

Location

12V
24V

LGP4

24 (2400K)
27 (2700K)
30 (3000K)
35 (3500K)
40 (4000K)
50 (5000K)
65 (6500K)
TW (Tunable White)
RGB (Color Changing)
WD (Warm Dim)
RGBW (Color Changing with White)

Example: 24
(L x W in.)
CSTM
(Custom Shape)

D (Diffused)
ND (Non-Diffused)

1
2
4

SL (Silver)
WH (White)
FMLS (Frameless)

BL (Black)
WH (White)

Example:4
(L in.)

BW (Bare Wire)
DC (Female DC)

SD (Side)
BK (Back)

[1-8]
(Refer to spec)

Dry Location:

Make

Voltage	12V
	24V

Model

LGP4

CCT	24 (2400K)
	27 (2700K)
	30 (3000K)
	35 (3500K)
	40 (4000K)
	50 (5000K)
	65 (6500K)
	TW (Tunable White)
	RGB (Color Changing)
	WD (Warm Dim)
	RGBW (Color Changing with White)

Dimensions	Example: 24 (L x W in.)
	CSTM (Custom Shape)

Diffusion	D (Diffused)
	ND (Non-Diffused)

Edges Lit	1
	2
	4

Frame Color	SL (Silver)
	WH (White)
	FMLS (Frameless)

Lead Wire	Color/Type	BL (Black)
	Color/Type	WH (White)
	Length	Example: 4 (L in.)
	Connection	BW (Bare Wire)
	Connection	DC (Female DC)
	Exit	SD (Side)
	Exit	BK (Back)
	Location	[1-8] (Refer to Spect)

Learn about voltage drop
